CHAUVIN ARNOUX F607 2000A AC / 3000A DC Clamp Meter w/ Bluetooth

Chauvin Arnoux F607 [P01120967] 2000A AC / 3000A DC Clamp Meter Bluetooth. Perfect for current and voltage measurement as well as power values, harmonics and more, the Chauvin Arnoux F607 Harmonic Clamp Meter is a truly versatile multifunctional clamp. With a 12-bit True RMS digital acquisition system, the Chauvin Arnoux F607 measures current levels to 2000A AC and 3000A DC, AC/DC voltage to 1000V, W/VA/var, pf and DPF power values, THD-f and THD-r, harmonics to the 25th order, resistance and continuity with audible tone and true InRush current. Featuring large 60mm jaws and CAT IV connection terminals, the F607 can be attached to a large range of conductors and is ideal for use on switchboards or for LV electricity production and distribution, industry, railways, etc. It is also suitable for lift/elevator technicians and other lifting and transport equipment specialists. Providing Automatic AC/DC detection, a large 10,000-count backlit display and a simple-to-use rotary switch for selecting functions, in addition to data recording and bluetooth interface / pc software, the IP54-rated F607 is a user-friendly instrument packed with features.

Part Number: P01120967
AC Current (RMS): 2000 A; DC and AC+DC: 3000
Voltage (RMS) AC: 200 mV to 1000 V; DC and AC+DC: 200 mV to 1,000 V
AC/DC voltage meausrements to 1000V
W/VA/var, PF and DPF power values
Harmonics up to 25th order, THD-f and THD-r
Ripple function
Resistance and audible continuity testing
MIN/MAX and peak analysis
True Inrush current measurements
Data recording
Bluetooth interface and PC software
10000 count triple display

Include:
(1) F607 - Harmonic Clamp Meter
(1) Set of Red/Black Banana Leads
(1) Set of Red/Black Crocodile Clips
(1) Set of Red/Black Test Probes
(1) PC Communication Software
(1) Operating Manual
