SEW 6305IN Digital HV Insulation Tester

Rp. 32,500,000

NOTE
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.

Digital 5kV High Voltage Insulation Tester.
Microprocessor-controlled.
Well isolated from contact. Well protected from surges.
4 Insulation test voltages: 500V, 1000V, 2500V, 5000V

2 Lines × 16 Characters LCD.
Microprocessor-controlled.
Tests insulation resistance up to 10 TΩ.
4 Insulation test voltages: 500V, 1000V, 2500V, 5000V.
AC / DC Voltmeter (30~600V).
Short-circuit current up to 5mA.
PI (Polarization Index) indication.
DAR (Dielectric Absorption Ratio) indication.
Auto-ranging on all insulation ranges.
Optical USB to RS-232 data transmission.
Well isolated from contact.
Well protected from surges.
2 built-in optical LEDs for data transfer.
Visual and audio warning of external voltage presence (≥30Vac or ≥30Vdc).
Auto-hold function to freeze reading.
Overload protection.
Adjustable testing duration: 1~30 minutes.
Internal memory for data storage.
Displays testing duration for insulation measurement.
Auto-off function.
200 measurement results can be saved in memory and recalled on display.

Accessories
Instruction manual,
Test leads,
Data transmission cable CA-232,
Compact disk (CD) for PC interface,
Alligator clips,
Batteries,
Test report.
