HIOKI 3561 AC Milliohm Hi-Tester Battery Tester

The Hioki 3561 Battery HiTester is a low resistance meter employing the four terminal AC method to measure the internal resistance (IR) of small secondary batteries while measuring battery voltage at the same time.  Compared to the Hioki 3560, performance capabilities have been greatly enhanced by increasing measurement speed tenfold to 10ms (measuring resistance and voltage simultaneously), and increasing voltage measurement accuracy nearly fivefold to 0.01% rdg.  The high-resolution 0.01mΩ (in the 300 mΩ range) and 0.1 mV capabilities are suited for production line battery testing.

Specifications
Measurement Ranges and Accuracy    300 mΩ to Ω, 2 ranges, ±0.5% rdg. ±5 dgt. 20V, ±0.01% rdg. ±3 dgt. (input impedance 1mΩ)
Measurement Current    10 mA (300 mΩ range) to 1 mA (3Ω range)
Max. Applied Measurement Voltage    ±22 V DC rated input voltage
±70 V DC maximum rated voltage above ground
Sampling Speed    Extra Fast: 7ms
Fast: 23ms
Medium: 83/69ms
Slow: 258/251ms
Displays    31,000 full digits (resistance), 19.9999 full digits (voltage), Fluorescent Tube
Measurement Method    Four-Terminal AC (1 kHz) Method
Comparator Functions    Setting: Upper and Lower Limit
Output: 3 Levels (Hi, In, Lo) or (Pass, Fail), Open-Collector, Display, Dual Audible Indicator
Panel Save/Load    Up to 126 Configuration Settings
Interface    External I/O, RS-232C, Printer(RS-232C), GP-IB(3561-01)
Power Supply    100 to 240 VAC (50/60 Hz)
