BK Precision 9173B Dual Channel Programmable DC Power Supply
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.
The BK Precision 9173B220V Programmable Dual-Output Dual-Range DC Power Supply, 10V/10A, 20V/5A, 220VAC Line Input delivers clean, stable and precise output power due to its exceptionally low ripple and noise, low temperature coefficient, excellent regulation, and fast transient response time characteristics. The 9173B-220V is well suited for both bench use and ATE applications. For bench use, the 9173B-220V offers an intuitive user interface with a full numerical keypad for convenient data entry. Research and design engineers will appreciate front panel output and remote sense terminals. Free application software is available for remote control without the need for any computer programming. USB and optional GPIB/LAN interfaces combined with a fast transient response and command processing time, make the 9173B-220V ideal for ATE applications. The 9173B-220V offers versatile LED test modes, modular interface card slots, automatic range selection, and an optional 8-bit bidirectional digital I/O interface. To protect the device under test (DUT), the 9173B-220V provides safety options such as OVP, OCP, and a key-lock feature to prevent accidental change of parameters that might damage the DUT.
Part Number: 9173B-220V
Output Voltage: 0-20V
Output Current: 0-10A at 0-10V, 0-5A at 0-20V
Input Current: 230VAC, 47 Hz - 63 Hz
200W dual output power
Exceptionally low ripple and noise
Dual range output with automatic range selection
Front and rear panel output terminals for convenient wiring
Rear and front panel remote sense terminal
List mode for executing up to 10 stored test sequences with a maximum of 150 steps in total
Store and recall up to 10 power settings
Overvoltage (OVP) and overcurrent (OCP) protection, including key-lock function
Transient response time of less than 50 microseconds
Less than 10 ms command processing time
Programmable voltage and current slew rates
Convenient voltage and current calibration via front panel
LED test modes for minimizing inrush current
SCPI compliant USB standard interface
4 optional types of modular interface cards add LAN and GPIB, Single channel digital I/O and analog control, RS485, or RS232 functionality
Application software available for remote control
Include:
(1) 9173B - Programmable Dual-Output Dual-Range DC Power Supply
(1) AC Power Cord
(1) USB Cable (Type A to B)
(1) Line Fuse
(1) User Manual
(1) Certificate of Calibration
(1) Test Report
