TECHNO-AC Success ATG-127E Acoustic Cable Fault Locator

High tech kit with multi-frequency transmitter for buried utilities detection and acoustic cable fault detection.

Features:
High precision location of underground utilities up to 6 m
Transmitter - 120W, frequency range: 200 to 9999 Hz
Distance of tracing is 5 km from the place of transmitter connection
Detection of insulation deterioration on cables by non-contact methods: sharp decreasing of the
      signal level, by using the sensor DODK (extra tool), the phase "double-frequency" method "Δφ" and the
      amplitude of "double-frequency" the method of "ΔA"
Detection of insulation deterioration on cables by contact method : Sensor DKI (extra tool)

Brief description:
Receiver frequencies: 50(60) Hz / 100(120) Hz / 512 Hz / 1024 Hz / 8192 Hz / 33 kHz
Transmitter - 120W, frequency range: 200 to 9999 Hz
Storage of 31 signal level with a graph displayed
Visual indication of the signal on the display: scale, graph and spectrum
Graphic visualization (moving chart) of sequence of measurements, max and min signal levels
Sound indication
Choice of bandwidth
Two-segment indication of frequency spectrum (and “filtered”) signal
Light weight
Comfortable to wear for long terms
LCD display

Application:
Cable fault location by electromagnetic and acoustic methods (with high-voltage pulse transmitter,
which is not included into the set)
Detection of insulation deterioration on cables by contact and non-contact methods
Detection of cables up to 6 m depth
Detection of metal pipelines up to 6 m depth
Survey the ground before the ground works
“Broadband” mode
Distance of tracing from the place of transmitter connection is up to 5 km
Indirect measurement of the depth

What's In The Box:
(1) Receiver AP-027
(1) Acoustic sensor AD-227
(1) Carrying rod for AD-227
(1) Extension carrying rod for AD-227
(1) Contact rods for AD-227
(1) Magnet for AD-227
(1) Electromagnetic sensor EMD-247
(1) Transmitter АG-120
(1) Inductive antenna IEM-301.3
(1) Headphones
(1) Grounding rod
(1) Cables and accessories
