TECHNO-AC Success ATP-434E Acoustic Cable Fault Locator

Rp. 135,000,000

NOTE
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.

Based on receiver AP-027, EMD-247 sensor and acoustic sensor AD-227.

Features:
AP-027 digital location receiver
Energized cable detection underground up to 6 m depth
Acoustic cable fault detection
Brief description:
Storage of 31 signal level with a graph displayed
Visual indication of the signal on the display: scale, graphic and spectrum
Graphic visualization (moving chart) of sequence of measurements, max and min signal levels
Sound indication: natural and synthesized sound
Broadband mode: 0.05 to 8.6 kHz
Broadband (fault mode): 0.09 to 2.20 kHz
Min and max method of tracing
Light weight
Comfortable to wear for long terms
LCD display

Application:
Detection of energized cable lines underground up to 6 m depth by passive method.
Cable fault location by electromagnetic and acoustic methods (with high-voltage pulse transmitter,
which is not included into the set).
Detection of insulation deterioration on cables by contact and non-contact methods.
Burial depth measurement by passive method.

What's In The Box:
(1) Receiver АP-027
(1) Electromagnetic sensor EMD-247
(1) Acoustic sensor AD-227
(1) Headphones
(1) Holder for АР-027
(1) Screwdriver
(1) Set carrying bag
(1) EMD carrying bag
(1) Operation manual
(1) Technical passport
