SKF TMMS 260 Tri Section Pulling Plate

Tri-section Pulling Plate, 90-260mm

The tri-section pulling plates SKF TMMS 260 are especially designed for use in combination with three-armed pullers. The plates grip behind the inner ring of the bearing. This prevents the pulling forces from being transmitted through the outer ring and the rolling elements, minimizing the risk of bearing damage. The tri-section pulling plates suitable for shafts with maximum diameter ranging from 50 to 380 mm (2 to 15 in).



Tri-section pulling plate (90-260mm grip width)

The unique design of the TMMS series allows the application of force on most efficient point; the inner ring, and thereby requiring less force for dismounting than when pulling on the outer ring

The firm grip behind the bearing's inner ring ensures that the pulling forces are only transmitted through the inner ring and not through the outer ring or the rolling elements, preventing bearing damage

The tri-section construction allows even force distribution, preventing bearing locking and/or tilting on the shaft, especially in the case of SRB and CARB®, during dismounting

Suitable for use in combination with any three-armed puller

Special wig shape allows the plates to be easily inserted between bearing and the shoulder on the shaft

Covering most common shaft sizes



Test Equipment General Attributes

Unique Features • Grip width 90-260mm

• Suitable for use in combination with any three-armed puller

• Special wig shape allows the plates to be easily inserted between bearing and the shoulder on the shaft

• Available in a wide range, covering most common shaft sizes

Product Weight 53.3789 LBS
