PROVIBTECH TR4102 Series Proximity Sensor

Rp. 22,500,000

NOTE
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.

Manufacturer : ProvibTech
Product No. : TR4102-E01-G00-S01
Product Type : TR4102 Proximity Loop Powered Transmitter
TR4102 Proximity Loop-powered Transmitter for Thrust Position
Probe and Cable (not included) : E01 = TM0180, 8mm Probe, 9m Cable
Mount : G00 = DIN rail mount, measure position
Hazardous Area : S01 = Multiple approvals, ATEX: II 1 G EEx ia IIC T4 @Ta=-40 ~ +70 ? ?
Power Supply : 16-30VDC
Sensor Interface : Special 95? coaxial cable with connector - 3,000Hz
4-20mA Transmissions
2-wire, load
Phase reference: frequency response: 0 - 10 KHz
Buffered Output (GAP V)
Raw position signal
Nominal : 2-18VDC
Impedance : 20 K?
Maximum cable distance : 3.0m (10ft)
Sensitivity : 8.0mV/um (200mV/mil) nominal
Frequency response : 0 - 10 KHz
Temperature
Operation : -40? to +70?
Storage : -40? to +100?
Humidity : 90% non-condensing
Weight : 0.50 Kg
Shipping Weight : 1.50 Kg
