STI CMCP 620VT Handheld Vibration Meter

The CMCP620V Vibration and the CMCP620VT Vibration and Temperature battery powered portable kits have been designed for use as both an entry level and also a comprehensive vibration and temperature monitoring instrument for maintenance engineers across all types of industries.

The CMCP620VT kit consists of the compact vibration meter with a combined non-contact temperature measuring sensor aided by a locator beam, a hand held probe, a magnetic mount for more permanent installations, a protective carrying case, an instruction manual and battery chargers for both mains and in-car use.

The meter is microprocessor based and by selection of the controls can be easily set up to monitor acceleration (g) levels, velocity (mm/sec), displacement (ìm), bearing condition (BG or BV) and temperature (°C or °F). A display hold function is also included.

The unit, which conforms to ISO 2954 and ISO 10816-3 also has an automatic alarm check for bearing condition.

Operating from an internal re-chargeable Lithium battery, the meter offers 48 hours continuous operation. From flat, the unit can be recharged in 3 hours using either the AC line or an in-car charger supplied with the kit.

Because of its compact size, ease of use and battery operation, the CMCP620 allows engineers to monitor vibration and temperature levels on important machinery anywhere around the factory

Futures:
Handheld Vibration Meter
Constant Current Accelerometer
100 mv/g
Acceleration, Velocity or Displacement
Optional Temperature (T)
Lithium Battery and Charger
LCD Display
0.8 meter Cable
75 mm Spike and 12 kg Magnet
Automatic Alarm Check ISO10816-3
IP 64
Includes Carry Case
