CHECKLINE TMG-1T Universal Benchtop Material Thickness Gauge
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.
The TMG series of digital material thickness gauges are designed for precision measurement according to ASTM, DIN, EN & ISO norms.
The TMG universal thickness gauges have a simple design and are easy to operate. Simply press the plunger to raise the contact foot and place sample below (lift lever on TMG-3). When you release the plunger the foot will contact the sample with the correct pressure per the respective measuring standard.
Thanks to its modular system, you can adapt the three basic types TMG-1, TMG-2 and TMG-3 to a large number of ASTM, DIN, EN and ISO standards without having to buy several measuring devices.
We have standard setups for the most common materials such as elastomers, textiles, leather, nonwovens, films, films, rubber, fabrics, geomaterials, paper, paper towels, and cardboard. We can also offer customized solutions (inquire).
Only the highest-quality materials are used in the manufacturing of the TMG thickness gauge as demonstrated by the laboratory grade granite base, stainless steel column and the highest quality aluminum boom. High-quality materials do not only guarantee longevity, but also high corrosion resistance even when used in high-humidity environments.
List of standards for ready-made configurations:
ISO-5084 for textiles
ASTM D 1777 Option 2 for textiles
ISO-23529 for rubber / elastomers
ASTM D3767 for rubber / elastomers
DIN EN ISO 12625-3 for waterproofing membranes
ASTM D 1777 Option 1 for fiber fabrics, knitwear, knitwear and structural textiles
ASTM D 1777 Option 5 for ceilings and pile fabrics
ISO 4593 + DIN 53370 for films and films
DIN EN ISO 2589 for leather
ASTM D 1777 Option 3 for Films and Glass Fibers
ASTM D 5199 for geosynthetics
DIN EN 534 for paper and cardboard
DIN EN ISO 3034 for corrugated board
Features
Includes Manufactures Calibration Certificate (ISO Calibration Cert Optional)
Precision Granite Base
USB Output
User Selectable Units of In or MM
Calibration Certification
The TMG does not include a calibration certificate standard however we do offer 3 options:
A manufacturer calibration certificate for the complete system
A DAkkS traceable calibration certificate, which refers purely to the dial gauge
An ISO-17025 Accredited calibration certificate, which refers purely to the dial gauge
