DAKOTA NDT PMX3-DL Precision Thickness Gauge
Rp. 145,000,000
NOTE
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.
Harga dapat berubah sewaktu-waktu mengikuti perkembangan kurs rupiah terhadap mata uang asing lainnya sehingga sangat mungkin terjadi adanya perbedaan harga yang berlaku dengan harga yang tertera pada website kami.
The Dakota PMX Precision Thickness Gauge offers user selectable resolution of either 0.01mm or 0.001mm (0.001/0.0001").
The auto find feature locates the detection point(s) and adjusts the display settings to bring the waveform into view.
The high speed scan feature on the Dakota PMX thickness gauge speeds up the inspection process by taking 250 measurements per second. Remove the transducer from the test material and display the minimum measurement scanned.
Features:
0.001mm high resolution
Range of display options: A-Scan, B-Scan, Pulse-Echo, Echo-Echo
Manual or AGC gain control with 110dB range, varies with mode selected
Automatic gain control (AGC)
User definable setups
Multiple language display
Visual and audible alarm with high and low limit settings for specific application tolerances.
Multiple calibration and material selection options
High speed scan: 250 readings per second
Differential mode
Minimal thickness alarm
Data output and storage: 4GB internal memory
Data management software
Technical Specification Dakota PMX Precision Thickness Gauges (PVX)
Part Number Description Certificate
Z-157-0006 Dakota PMX2-DL Precision Thickness Gauge (PVX)
Calibration Certificate supplied as standard
Z-157-0007 Dakota PMX3-DL Precision Thickness Gauge (PVX Colour)
Calibration Certificate supplied as standard
Operating Temperature -10 to 60ºC (14 to 140ºF)
Power Supply 3 x AA batteries and via USB
Battery Life Alkaline: greyscale 35 hrs, colour 12 hrs
Nicad: greyscale 10 hrs, colour 5 hrs
NI-MH: greyscale 35 hrs, colour 12 hrs
Gauge Weight 383g (13.5oz) - including batteries
Gauge Dimensions 63.5 x 165 x 31.5mm (2.5 x 6.5 x 1.24”)
Packing List Unit, standard 1/4" Delay Line Transducer (2 Delay Tips – 3/8” & 1/2” L) & Cable, Couplant, Manual, Certificate of Calibration, AA Batteries and Plastic Carrying Case.
