AMETEK CTC350 Temperature Calibrators

The Ametek CTC Series is a fast, time-saving, reliable dry block temperature calibrator designed for on-site use. Available in three models with ranges from -25 to 155°C (-13 to 311°F), 28 to 350°C (82 to 662°F), and 28 to 660°C (82 to 1220°F); the CTC series offers the speed, portability, cleanliness, and wide temperature range which are all superior to liquid bath systems.

The CTC series provides exceptional accuracy and stability. The large color display is easy-to-read and provides icons and information regarding the status of the calibrator and the calibration in process. Popular functions like automatic switch test and auto stepping are available with special one-key-one-function buttons. When switching on the calibrator or connecting the reference sensor, the calibrator immediately warns you if any of the calibration certificates are overdue. A buzzer and warning appears. The recalibration interval can be set from 1 to 99 months.

The CTC series is available with an optional signal input for an external reference sensor. The sensor makes it possible to improve accuracy even more. The CTC can be run in two modes when using the external reference sensor. "External ref" mode is where the external reference sensor represents the True value. The "Set follows True" mode is where the reference sensor serves two purposes; measuring the reference temperature and at the same time controlling the block temperature to the set temperature

The Ametek CTC is supplied with our highly versatile calibration software JofraCal. All calibrations can be documented with a certificate, given that the CTC is controlled from a PC. When the calibrator has reached the desired temperature and stabillity it will prompt you to type in the UUT temperature. JofraCal documents all your calibration needs within temperature, pressure and process calibration.

Features:
Temperature range:
CTC-155: -25 to 155°C (-13 to 311°F)
CTC-350: 28 to 350°C (82 to 662°F)
CTC-660: 28 to 660°C (82 to 1220°F)
Accuracy:
CTC-155: up to ±0.2˚C (±0.36˚F)
CTC-350: up to ±0.25˚C (±0.54˚F)
CTC-660: up to ±0.45˚C (±0.81˚F)
Stability:
CTC-155: ±0.04˚C (±0.07˚F)
CTC-350: ±0.05˚C (±0.09˚F)
CTC-660: ±0.1˚C (±0.18˚F)
Heating time:
CTC-155: 13 minutes (from 23 to 155°C / 73 to 311°F)
CTC-350: 6 minutes (from 23 to 350°C / 73 to 662°F)
CTC-660: 18 minutes (from 23 to 660°C / 73 to 1220°F)
Well depth: 115mm (120mm for CTC-155)
Well diameter: 26mm
Informative color display and intuitive operation
Wide range of insert options avaialble
Optional input for external reference sensor
MVI circuitry ensures stability despite mains supply variations
Silent mode operation
Lightweight and easy to carry

What's in the Box:
(1) Mains power cable (user specified)
(1) Traceable calibration certificate
(1) Tool for insertion tubes
(1) Insert (user specified)
(1) User manual
(1) Test cables (1 x red, 1 x black)
(1) USB cable
(1) JofraCal calibration software
(1) Heat shield (CTC-660 only)
