HT Instruments SOLAR 300N Solar Installation and Power Quality Analyzer

SOLAR300N tests the efficiency of a  single-phase and three-phase photovoltaic systems. For this kind of tests, it is necessary to guarantee simultaneity between power measurements carried out at the inverter and irradiation and temperature measurements carried out on the photovoltaic panels. HT Italia has solve this problem by creating a remote measuring device SOLAR02 which acquires the values of solar Irradiation [W/m2], panel Temperature [°C] and environmental Temperature [°C] and transfers them onto SOLAR300N, which inserts them onto the same string of power measurements an then elaborates them with the simultaneity required by the law in force.

At the end of calculation, the indication of a positive or negative result of testing appears on the display of SOLAR300N. SOLAR300N is not only a device for testing PV systems, but also a powerful device for a complete analysis of mains quality according to standard EN50160 (harmonic analysis, voltage anomalies, flickers, unbalance, etc.).

Features:
DC/AC TRMS (single-phase and three-phase) current measurement
DC/AC (single-phase and three-phase) power measurement
AC (single-phase and three-phase) energy measurement
DC Measurement of power factor (cosphi) single-phase and three-phase
Measurement of solar irradiation [W/m2]
Measurement of temperature by means of probe PT1000
Recording of voltage and current harmonics up to the 49° order
Recording of voltage anomalies (dips, peaks)
Flicker analysis in compliance with standard EN50160
Recording of starting currents with a resolution of 10ms
Recording of voltage fast transients (spikes) with a resolution of 5us
Complete analysis of mains quality in compliance with standard EN50160
Numerical and graphical display of each quantity
Recalling results on the display
TFT colour display with touch screen
Power supply with rechargeable Li-ION battery
Memory extension by means of compact flash (CF card)
Data transfer to external USB memory (memory stick)
USB port for PC connection
Help on line at display

What's in the Box:
(1) HT4004N, 100A DC Transducer Rigid Clamp Meter
(1) User manual and quick guide
(1) PT400Touch, Screen Pen
(1) C2007, USB Cable
(1) TOPVIEW2007, Software on CD-ROM and USB connection cable
(1) YABAT0003HT1, Li-Ion 3 7V Rechargeable Battery
(1) A0055, Power Supply 230V / 50-60Hz EU Plug
(1) KIT800, 5 cables (black/blue/red/green/brown) 5 alligator clips (black/blue/red/green/brown)
(1) HT4005K, 200A AC Transducer Rigid Clamp Meter
(1) VA500 Hard Carrying Case
(1) SOLAR02, Remote Unit for Recording Irradiation and Temperature
(1) HT304N, Reference cell with tilt stand and connection cable
(1) ISO9000, calibration certificate
